Titanium

Titanium is a chemical element with the symbol Ti and atomic number 22. It has a low density and is a strong, lustrous, corrosion-resistant (including sea water, aqua regia and chlorine) transition metal with a silver color. Titanium was discovered in Cornwall, Great Britain, by William Gregor in 1791 and named by Martin Heinrich Klaproth for the Titans of Greek mythology. The element occurs within a number of mineral deposits, principally rutile and ilmenite, which are widely distributed in the Earth's crust and lithosphere, and it is found in almost all living things, rocks, water bodies, and soils. The metal is extracted from its principal mineral ores via the Kroll process or the Hunter process. The two most useful properties of the metal form are corrosion resistance and the highest strength-to-weight ratio of any metal. In its unalloyed condition, titanium is as strong as some steels, but 45% lighter. There are two allotropic forms and five naturally occurring isotopes of this element, 46Ti through 50Ti, with 48Ti being the most abundant (73.8%). Titanium can be alloyed with iron, aluminum, vanadium, molybdenum, among other elements, to produce strong lightweight alloys. Titanium Applications: 1, Aerospace Applications: aircraft, spacecraft, Jet Engines, Airframes; 2, Industrial Applications: Nuclear Power Generation, Chemical Processing, Chlor-Alkali, Petroleum, Desalination plants, pulp and paper, etc; 3, Emerging Applications: Geothermal Power; 4, Consumer and Architectural: automotive, racing motorcycle, bicycle,glasses,cookware, eating utensils, horseshoes, shovels and flashlights,watch, jewelry,mobile phones, body of laptop computers (for example,in Apple's PowerBook); 5, Medical Industry: orthopedic implants, dental implants; 6, Sporting Goods: tennis rackets, golf clubs, lacrosse stick shafts; cricket, hockey, lacrosse, and football helmet grills.


Titanium Plate


With feature of low density, light, high strength, well corrosion-resistance, mechanical and welding, titanium is widely used for chemical equipment, generating set, desalination equipment, boat parts, electroplate.








Grade

Grade1, Grade 2, Grade 3, Grade 4, Grade 5, Ti-6AL4V ELI, Grade7,Grade 9, Grade 12

Thickness

0.5mm--40mm, 40mm-60mm

Size

1000*2000mm, 2400*6000mm

Surface

Pickling or Polishing

Technics

Hot, cold rolling or annealed



Titanium Round Bar


Titanium has the characteristics of high-strength, heat high strength, corrosion resistance, low thermal conductivity, modulus of elasticity. So, it is widely used for petroleum, powder industry, desalination of sea water, alkali industry, coking industry.






Titanium bar specification :

Material

Titanium

Grade

Gr1, Gr2, Gr3, Gr4, Gr5, Gr7, Gr9, Gr12

Standard

ASTM, JIS, AMS, DIN

Application

Industrial,Medical

Size

As customers' request



Titanium Wires


According to usage, titanium wire can be divided in to two categories: structure wire, mainly used for structure and fastener; welding wire, mainly used for electrode material and welding material. It is widely used for military industry, medical, sports, glasses, earnings, electroplate hangers and so on.







NAME

Titanium Wire

STANDARD

AWS A5.16, ASTM B348, ASTM B863, ASTM F136, ASTM F67

GRADE

Gr. 1, Gr. 2, Gr. 5, Gr 7, Gr. 9, Gr. 12, Gr. 23

DIMENSION (MM)

Dia. 0.8-5.5 * Coil / Straight



Titanium Square Tubes


Titanium seamless square tubes according to ASTM B337,ASTM B338.












Titanium Welded Pipes and Tubes












Production

Welded Titanium and Titanium Alloy Tubes & Pipes

Specification

ASTM B337, ASME SB338, ASTM B338, ASTM B861, ASTM B862

Material Grade

Gr1, Gr2, Gr4, Gr5, Gr7, Gr9, Gr11, Gr12 etc.

Dimension Range

OD 3.0-114.0mm, WT 0.2-10.0mm, L18000mm

Application

Heat exchanger, cooling tower, aviation, medical, industry etc.

Grade

Condition

Outside
Diameter
(mm)

Thickness
(mm)

Standard

0.2

0.3

0.5

0.6

0.8

1.0

1.25

1.5

2.0

2.5

3.0

3.5

4.0

4.5

5.0

10.0

Gr1
Gr2
Gr5
Gr7
Gr9
Gr12

R
M
Y

3~5

























ASTM B337
ASTM B338
ASTM B861
ASTM B862

>5~10





















>10~15



















>15~20



















>20~30

















>30~40



















>40~50



















>50~60

















>60~80















>80~114





















Titanium Seamless Tubes and Pipes


Titanium seamless tube is widely used for heat exchanger, such as shell and tube heat exchanger, coiled tube heat exchanger, condenser, evaporator and running pipe.







Titanium seamless tube specification :

Material

Titanium Gr1,Gr2,Gr5,Gr9

Size

As customers' request

Application

Industry,petrochemical,medical



Titanium Ball


Specifications
Titanium ball
Material:titanium ,titanium alloy
Titanium grade;titanium gr1,2,4,5,7,9


We also can make products according to your drawing or sample.







Titanium Strip /Foll


Titanium strip, titanium foil, titanium coil
1.Material : Gr1 Gr2 Gr3 Gr4 Gr7 Gr9 Gr18
2.Standard: ASTM B265 AMS4911 AMS4916 DMS1592F MIL-T-9046
3.Size(mm):thickness:0.005mm-0.1mm * width: 50mm-300mm * Length≥500
                    thickness:0.01~0.02*width:30~100*length≥500
                    thickness:0.03~0.09*width:50~300*length≥500
4.Ti-0.15Pd(Gr7), Ti-3Al-2.5V(Gr9), Ti-0.3Mo-0.8Ni(Gr12), Ti-6Al-4V ELI(Gr23)

Titanium is made of high quality titanium sponge powder, whose has much special application. Titanium coil is mainly used for civil aviation plane, military plane, aerospace craft, nuclear submarine, power plant and other high-tech area.



Titanium Tube Coil / GR2 ASTMB348 Titanium Coil


Name Titanium Coil
Material GR2 GR12
Standard ASTM B337,ASTM B338
Size of tube 25*1.5mm 32*2mm 45*2mm 51*2mm 68*3mm 76*3mm 89*3mm and so on
Style Titanium Coil.Snakelike-titanium coil.U-titanium coil.Titanium double coil.Titanium coil type heat exchanger.Titanium double set coil.U-titanium coil type heat exchanger.Titanium tube type heat exchanger.Suspension type titanium coil.Double inlet and double outlet single-layer titanium coil.single-layer titanium coil and multi-layer

Titanium coil with a large application range on chemical industry.petroleum.metallurgy.electricity generation.desalination plant.chlor-alkali.salt manufacturing.Titanium coil also use for produce titanium pigment.glycin.Saltpetre amino phenol.pesticide.Chemical fuel.Pesticide intermediates.cyanuric acid.dichlord isocyanurice acid.trichlorocyanuric acid.

Advantages
1) Titanium with a good corrosion resistance. Then the thickness of coil can be thinner. It can develop the heat-conducting property of heat exchanger.
2)Polish of surface without schmutzband then make the dirty factor be very low
3) low density, High strength, The same volume will with a lower quality than most of the metal.


Titanium Forged Disc/Ring












Products Name

Titanium Disc/Ring

Material

GR2 (CP Ti)

Size

OD 100~1300mm, H10~700mm or customized size as drawing.

Standards

ASTM B381/ B348

State

M/R

Processing

Hot forging

Surface

Bright, Polished, Pickling, Acid cleaning

Technic Test

Tensile test, Visual, Ultrasonic, Macro-structure, Micro-structure
